Collision and crime scene investigation with drones

The Royal Canadian Mounted Police use drones to document collisions and crime scenes. But do they measure up to traditional methods?

Drones and drone mapping allows investigations to be conducted under all weather conditions and provides broader views than traditional procedures.

Do drones measure up?

A demonstration project was designed to compare drones to traditional methods of surveying (measuring tape, laser scanner).

A demo crime scene, featuring a dummy on the ground surrounded by several cars.
Dummy was used to create the demo crime scene

Measurements were taken with both drones and traditional methods to demonstrate the accuracy and reliability of the achieved reconstruction results so that they can eventually be used as admitted evidence in court.

Project details

OrganizationThe Royal Canadian Mounted Police (RCMP)
Industry Public Safety
Project DateSeptember 2014
Project MembersDraganfly, Aeryon Labs
Project Size3.1 Acre
Number of Images212
GSD1 cm
Software Pix4Dmapper photogrammetry software

Collecting evidence using drones

Two data sets of a made-up crime scene were acquired with quadcopters from Aeryon Labs and Draganfly. The ground sampling distance was less than one centimeter in order not to miss any details.

Police officer making notes in front of an emergency vehicle.
Police officer taking notes for the collision scene analysis

The full flight took less than thirty minutes including the pre-flight preparation. Eight yellow evidence markers were placed around the collision scene, indicating the location where all evidence was found.

Cross examination of the results

Pix4Dmapper's total processing time was approximately two hours on a laptop with a core i7 CPU and 8GB RAM. A densified point cloud, digital surface model (DSM) and orthomosaic were generated. Annotation and measurements were directly made in the software user interface.

Reconstruction of the collision scene with measurements
Reconstruction of the collision scene

The reconstructed results either exactly match or are within one centimeter accuracy when compared with traditional methods (tape measurements and laser scanner). Detailed comparisons of results can be found in the White Paper.

Case closed

Using drones and Pix4Dmapper to reconstruct accident and crime scenes provides an immediate response, saves time and expense and offers highly accurate outputs. This has been proven again and again, such as in the case of a minibus from the Providence center accident in the USA, generated results are available permanently and users can access files and make measurements anytime when required to. Actual scenes are preserved in 3D and with detailed information within centimeter accuracy.

As we also discussed with Aerial Metrics, drones and aerial mapping have become the go-to solution for crash investigation and reconstruction.

Full project model in 3D

Compared to other precision instruments such as laser scanners, the cost of execution and maintenance of drone mapping is much lower.

Watch our webinar to learn how innovative public safety organizations are incorporating drone mapping into their operations.
